Mobile Jaw Crusher

YSE Mobile Jaw Crusher

introduce
YSE Mobile Jaw Crusher Plant is a series of new rock crushing equipment developed by YUSHENG company, which can work in narrow and terrible conditions. The mobile jaw crusher station is equipped with a high-performance mobile jaw crusher, vehicle-mounted feeder and high-strength vibrating screen. It has the advantages of short length, light weight, strong mobility, strong adaptability, reducing the transportation cost of materials, and flexible combination. No matter coarse crushing, fine crushing or sand making operation, YSE mobile jaw crusher plant is designed based on the conception of fully adapting various crushing conditions,  eliminating obstacles caused by location, environment, foundation configuration, consequently providing simple, efficient, low-cost crushing equipment. It is mainly used for processing material in metallurgy, chemistry, building materials, hydro power and other industries that often requires mobile base stations. The mobile jaw crusher station has greatly expanded the concept of coarse crushing.
YSE69

Model

ZSW380×96

Vibrating  Feeder

PE600x900

Crusher  model

B800×8.5M

Main  Conveyor

B650×3.5M

Seconday conveyor

2

Number of Axles

Feature
Deatails
Technical Parameter
Case
product Feature
Equiped with high performance jaw crusher, cone crusher or impact crusher
Equiped with high performance jaw crusher, cone crusher or impact crusher
Tractive steering shaft, convenient for road transportation
Integrated with landing gears, quick and convenient installation on site
Integrated motor and control panel
product Deatails
Capacity:100-500T/H Note: specific production capacity is based on customer site configuration and production capacity.
Applicable Material: River pebble, limestone, granite, basalt, iron ore, marble , shale, coal, cobblestone, construction waste.
Application Field: Many industries such as mining, building materials, smelting, railways, highways, hydropower and chemical industry
product Technical Parameter
Model Vibrating  Feeder Crusher  model Main  Conveyor Seconday conveyor Number of Axles Capacity (t/h) Power Hydraulic  system

YSE96 ZSW380×96 6CX96 B800×8.5M B650×3.5M 2 100-200 101.5 Hydraulic lifter
YSE110 ZSW420×110 6CX110 B1000×8.5M B650×3.5M 3 250-500 192 Hydraulic lifter
