Mobile Sand Making Machine

YSV Series Mobile Sand Making Machine Plant

introduce
YSV series mobile sand making machine (sand making&shaping) plant overcomes the problem of combining traditional mobile crusher stations with artificial sand making & shaping equipment, it is an ideal equipment in the field of artificial sand making and gravel shaping. Mobile Sand Making Machine Plant is equipped with VSI series or 5X series high-efficiency vertical shaft impact crusher + vibrating screen fine crushing shaping screening mobile station, which can make the crushed products have a reasonable gradation, and the crushed sand and gravel particles will form cubes with uniform particle size, which is especially suitable for concrete sand.
<45mm

Feed size

240-500(T/H)

Capacity

249.5-357.5kw

Power

Feature
Deatails
Technical Parameter
Case
product Feature
Strong Flexibility
The crushing equipment is installed on an independent movable chassis, with short wheelbase and small turning radius. It can be driven flexibly on ordinary roads and working areas.
Reasonable Configuration
Equipped with large crushing ratio, powerful vertical shaft impact crusher and high-performance screening box, automatic screening movement and adjustment to improve screening efficiency.
The finished product has excellent grain shape and cubic shape
The crushed product has a reasonable gradation, and the crushed sand and gravel particles form cubes with uniform particle size, which is especially suitable for concrete sand.
Wide range of applications
Through the combination of different models, a powerful crushing production line can be formed to complete multi-demand processing work.
product Deatails
Application field: Mining, Building Materials, Metallic Minerals, Recycled Aggregate, etc
product Technical Parameter
Model Crusher Model Vibrating Screen Conveyor Below Sieve Main Conveyor Number of Axles Capacity (t/h) Dimension
(L*W*H)
(mm)
Hydraulic System
YSV85 VSI8518 3YA1848/
3YA1860
B1200×8.7M B1000×7.5M 3 100-130 14920×3660×7100 Hydraulic lifter
YSV95 VSI9526 3YA1860/
3YA2160
B1200×8.7M B1000×7.5M 3 150-190 14920×3660×7100 Hydraulic lifter
