Mobile Cone Crusher

YSC Mobile Cone Crusher

Mobile cone crushing equipment is a series of new rock crushing equipment developed by YUSHENG company, which greatly expands the concept field of coarse crushing and fine crushing operation. Mobile cone crusher is mainly composed of high-performance Symons or Hydraulic cone crusher, circular vibrating screen, belt conveyor, motor ,electric control cabinet and hydraulic system. The whole mobile crushing plant adopts integrated installation and coordinating work, which fully represents its advantages of convenience and flexibility. Mobile cone crusher has the advantages of large capacity, high efficient, medium strength and fine crushing, and has strong adaptability, it adopts self loading conveyor for crushing and screening. The mobile cone crushing plant is suitable for the mobile crushing of construction rubble and mining area, especially suitable for crushing various ores and rocks with medium hardness or higher hardness.



Crusher  Model


Vibrating Screen


Main Conveyor


Frame Chassis


Capacity (t/h)

Technical Parameter
product Feature
Equipped with high efficient cone crusher, it has excellent crushing performance.
Optimized crushing cavity can significantly increase crushing ratio and output.
Supporting legs adopt hydraulic lift mode which is of convenient operation and stable performance.
It has the feature of great production capacity, high reliability, easy maintenance, lower customer production costs.
Easy to adapt and flexible to collocate with other machine.
product Deatails
Capacity:70-285 T/H Note: The specific production capacity depends on the customer's site configuration and production capacity.
Applicable Material: Limestone, granite, marble, basalt, iron ore, river pebble, coal, cobblestone, construction rubble etc.
Application Field: Many industries such as mining, smelting, building, highways, railways, water conservancy and chemical industry
product Technical Parameter
Model Crusher  Model Vibrating Screen Main Conveyor Frame Chassis Capacity (t/h) Dimension(L*W*H)
Hydraulic  System
YSCS75 CS75 3YA1848 1 Triaxial 180-270 18000×3900×6900 Hydraulic  lifter
YSCS160 CS160 3YA2160 1 Triaxial 132-253 18000×4200×6900 Hydraulic  lifter
YSHP200 HP200 3YA1848 1 Double Axle 70-160 12600×3000×4500 Hydraulic  lifter
YSHP300 HP300 3YA1860 1 Triaxial 90-285 13800×3000×4500 Hydraulic  lifter
