Hammer Crusher
Hammer Crusher

Hammer Crusher

introduce
Hammer Crusher by collisions with material of the high-speed rotating hammer body and crushing material, it has a simple structure, big crushing ratio, high production efficiency etc, can make dry, wet two forms. Hammer crusher for crushing all kinds of medium hard and abrasive weak material. The material does not exceed 300 mpa compressive strength, water content less than 15%.Being broken material for coal, gypsum, salt, chalk, cement, brick, tile, limestone etc.
≤200-≤350mm

Feed Size

 5-150m³/h

Capacity

11-480kw

Power

Deatails
Technical Parameter
Case
product Deatails
Working Principle The main working part of hammer crusher is the rotor with hammers. The rotor consists of main shaft, disk, hinge pin and hammers. A sieve plate is below the rotor. The motor drives the rotor to rotate at a high speed. When the material get into the crushing cavity, they are crushed by the rotating hammers, the crushed products which meet the required size can be discharged from the sieve plate and become the final products, the products with large size are brought back to the crushed area for being re-crushed until they reach the required size.
Application: Hammer crusher can crush medium-hard or brittle materials with hardness less than 300Mpa and 15% moisture, such as coal, gypsum, alumen, cement, brick, limestone, tile, etc.
product Technical Parameter
Model Rotor speed (r/min) Input opening size(mm) Max. feed size(mm) Discharged size(mm) Capacity (t/h) Power (kw) Weight (t)
Φ400×400 1500 145×450 100 0-30 5-8 7.5 0.9
Φ600×400 1000 295×450 100 0-35 10-12 18.5 1.03
Φ600×600 1000 295×570 100 0-35 12-18 45 2.14
Φ800×600 1000 350×570 120 0-45 20-25 55 2.45
Φ800×800 1000 350×850 120 0-45 35-45 55 3.05
Φ1000×800 1000 580×850 200 0-45 25-40 110 6.5
Φ1000×100 1000 580×1060 200 0-45 40-80 132 7.6
Φ1250×800 750 650×850 200 0-45 20-50 132 11.7
Φ1250×125 750 650×1330 200 0-45 90-110 185 13.2
Φ1400×140 750 1050×154 250 0-45 120-170 280 17.2
Φ1600×160 600 1500×178 350 0-60 220-280 450 22.8
